Silicosen Bio-Silico is a sponge plug made using a forming technology and designed for permeable and bacillus-safe test tubes. Bio-Silico is durable, easy to use, and suitable for cultivation.



[Industrial field]

Medical equipment

Performance

[Applications]

  • Cultivation and preservation of bacteria (I mildew, leaven and bacteria)

Characteristics

  • Easy to use in comparison to cotton plugs which means that massive savings can be made in labor and labor costs.
  • Moisture evaporation rate is less than half of cotton plugs which means that heteropycnosis of the culture solution and PH changes are reduced.
  • Excellent heat resistance property which means that plugs can be dry sterilized (180℃）and high pressure steam sterilized for repeated use.
  • Excellent chemical resistance property.
  • Can be hot water washed and disinfected. Also can be washed in neutral detergent.
  • Hydrophobic property means that bacteria proliferation is suppressed at the sealing area with the container.

Specifications

Silicosen and Bio-Silico are handled more easily than conventional cotton plugs.

Specifications

Shin-Etsu　SILICOSEN

Configuration

T-Type

L-Type

C-Type

S-Type

※Mark has green color.

Type Model No. Size(mm) Application
D1
(d1)		 D2
(d2)		 L1
(d3)		 L2
(ℓ1)
Plug Type T-Type T-10 10 6 13 17 For small culture tube
T-12※ 12 9 14 17
T-15 15 11 15 20 For medium sized culture tube
T-17※ 17 13 10 30
T-19※ 19 15 12 30 For large culture tube
(inside diameter 18mm)
T-22 22 18 15 30 For large culture tube
(inside diameter 20mm)
T-24 24 20 21 31 For 50cc flask
T-28 28 20 20 35 For 100cc flask
T-32 32 22 23 32
T-38 38 26 30 45 For 300 ~ 500cc flask
T-42 42 32 35 50 For 1000cc flask
T-52 52 42 40 60 For large spout bottle
T-66 66 54 40 60
T-76 76 64 40 60
L-Type L-12 12 9 40 10 For small culture tube
L-17 17 13 30 20 For medium sized culture tube
L-22 22 18 30 30 For large culture tube
(inside diameter 20mm)
Cap Type C-Type C-20 16 12 20 28 For medium sized culture tube and 50cc flask
C-30 26 18 30 28 For 100cc flask
C-40 36 27 40 28 For 300 ~ 500cc flask
C-55 50 34 55 28 For 1000cc flask
C-65 57 42 65 29 For 3000cc flask
Super Type S-Type S-28 28 17 18 27 For large size test tube and 100cc flask
S-35 35 24 20 30 For 300 ~ 500cc flask
S-40 39 28 20 30 For 500cc flask

Shin-Etsu BIO-SILICO

Configuration

Type Model No. Size(mm) Application
D1
(d1)		 D2
(d2)		 L1
(d3)		 L2
(ℓ1)
BIO-SILICO N-12 13 9 13 17 For small culture tube
N-15 16 11 14 22 For medium sized culture tube
N-17 19 13 15 25
N-19 21 15 16 28 For large culture tube (inside diameter 18mm)
N-22 24 18 18 30 For large culture tube (inside diameter 20mm)
N-24 26 20 20 32 For 50cc flask
N-28 30 21 20 34 For 100cc flask
N-32 34 22 24 36
N-38 40 26 30 44 For 300 ~ 500cc flask
N-42 44 30 32 46 For 1000cc flask
N-52 54 40 36 50 For large spout bottle

Catalog
