『EXELAST®』 SX Series

Olefin compound that is used for surrounding parts of automotive window.

[Industrial field]

Automobile

Performance

[Applications]

Surrounding parts of automotive window（Glass run channel）

Characteristics

SX Series is the silicone and olefin thermoplastic elastomer.
Excellent low friction and durability last from initial to long term.
Reduce squeak noise drastically in friction.

Technical data

Application	Part number	Basic physical properties				Basic physical properties	Basic physical properties	Basic physical properties	Characteristics
Application	Part number	Application	Part number	Specific gravity	Tensile strength （MPa）	Elongation （%）	Hardness	Characteristics	Characteristics
Glassrunchannel	SX-590	0.95	13.0	215	49 * *Shore D	High-slide, noise reduction

Back to High Functional Materials
