『Shin-Etsu PVC Namiita for livestock sheds』

(JIS certification JIS A 5702)
It is a corrugated sheet that can create the appropriate brightness and temperature required for livestock sheds.

『Shin-Etsu PVC Namiita for livestock sheds』

(JIS certification JIS A 5702)
It is a corrugated sheet that can create the appropriate brightness and temperature required for livestock sheds.

[Industrial field]

Construction, Civil engineering, Agriculture

Performance

[Applications]

Livestock sheds

Compost house

etc.

Characteristics

The environmental conditions required for livestock sheds are moderately maintained brightness and temperature due to soft sunlight. The Shin-Etsu Namiita for livestock sheds blocks the sunlight softly and spreads calm diffused light to every corner. The elegant milky white blends with the surrounding landscape to create an impressive sculptural beauty.

Specification table

（Unit：mm）

	Color	Thickness	Width	Depth	Number of corrugated waves (reference)	Effective width	Length	Number of packages
32nami	White	0.8 1.0	655	9	20.5	575	1,820 2,120 2,420 2,730 3,030	10
63nami	White	1.0 1.5	720	18	11.5	625	1,820 2,120 2,420 2,730 3,030	10

Color variations

White

PVC Namiita Ridge board・Drainer

（Unit：mm）

	Ridge board 32nami / Ridge board 63nami	Drainer (Eaves bend) 32nami

Color

White

Thickness

0.8／1.0

0.8

Shapes
